Liquid concealer foundation jar filling and capping machine

1.Target Products

2.Descriptions

• Model EGFC-01A is equipped with one filling nozzle
• Not only suit for cool filling products, such as skincare cream, cosmetic oil, serum, lotion, toner, shea butter, body butter etc...
• But also suit for hot filling products, such as foundation, concealer, petroleum jelly, face balm, balm stick, liquid powder, liquid eyeshadow, blush cream, cleansing cream, eyeliner cream, ointment, hair pomade, shoe polish etc...
• Both filling and capping are controlled by servo motor. Filling volume and capping torque can be set on touch screen directly
• With one set of 25L layer jacket with heater and mixer. Heating time and heating temp erature and mixing speed adjustable
• Heating can turn on/ off as demands
• The filling nozzle for room temp filling can move up/ down and achieve filling from bottle bottom to up
• Filling nozzle height can be adjusted as bottle/ jar/ pan size
• Piston filling system, easy product change and cleaning
• Servo motor control accuracy +-0.03g
• Touch screen control system
• Component parts brand: PLC& Touch screen is Mitsubishi, Switch is Schneider, Relays is Omron, Servo motor& Sensor is Panasonic, Pneumatic components is SMC
• Options
• Air cleaning machine to remove dust inside bottle before filling
• Automatic feeding pump to feed liquid product into filling tank automatically
• Automatic heating tank with pump to feed hot liquid product into filling tank automatically
• Automatic labeling machine after capping to finish labeling automatically

3.Specifications and Parameters

4.Details

Pump for feeding material	30L tank with mixing and heating	Room temp filling nozzle	Hot fill nozzle, fill from bottom to up
Filling with ceramic valve	Capping torque adjustable	Dust remove before filling	Heating tank(Option)

5.Reference Video
